The QUINT4-PS/1AC/12DC/15 Industrial Power Supply is rugged AC to DC and DC to DC Converter built to meet the high stability and efficiency expectations of industrial, machine automation and process control environments. It is capable of delivering power using a DIN rail bus distributor (TBUS adapter) and it can be directly latched onto the DIN rail. Featuring a protective coating, IECEx, ATEX, and HazLoc approvals, this power supply can be used in the harshest environments.
The OVP (overvoltage protection) of <30 VDC protects your system against voltage increases. In the event of an error, the output is switched off to protect the loads against overvoltage. The output circuit is decoupled by a MOSFET.
QUINT Power Supplies are exceptionally small yet offer superior system availability in the sub 100 W power range.
- Static boost of up to 125% (PN) for a sustained period
- Dynamic boost of up to 200% (PN) for 5 s
- Space-saving Slim design
- Preventive Function monitoring through adjustable signaling of power thresholds or output voltage
- Durable- Efficiency up to 94%- Low power dissipation
- General Information
- Manufacturer
- Perle Systems, Inc
- Manufacturer Website Address
- http://www.perle.com
- Brand Name
- Perle
- Product Line
- QUINT
- Product Type
- Power Supply
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Efficiency
- 94%
- Reliability
- MTBF
- 2000000 Hour
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Input Voltage Range
- 100 V AC - 240 V AC
- Output Voltage
- 24 V DC
- Output Voltage Detail
- 24 V DC @ 2.5 A
- Output Current
- 2.50 A
- Output Power
- 60 W
- Input Frequency
- 50 - 60 Hz
- Environmental Conditions
- Minimum Operating Temperature
- -25°C
- Maximum Operating Temperature
- 70°C
- Physical Characteristics
- Form Factor
- DIN Rail Mountable
- Height
- 99 mm
- Width
- 40 mm
- Depth
- 114 mm
- Weight (Approximate)
- 250 g
- Miscellaneous
- Certifications & Standards
- EN 50121-3-2
- EN 50121-4
- EN 50121-5
- IEC 62236-3-2
- IEC 62236-4
- IEC 62236-5
- EN 61000-3-2
- IEC 61010-1 (SELV)
- IEC 61010-2-201 (PELV)
- IEC 61558-2-16
- IEC 61010-2-201
- IEC 61010-1
- IEC 61010-2-201 (SELV)
- EN 61558-2-16
- EN 61010-1 (II (≤ 5000 m))
- EN 62477-1 (III (≤ 2000 m))
- ANSI/UL 121201 & CSA C22.2 No. 213-17 Class I, Division 2, Groups A, B, C, D T4 (Hazardous Location)
- UL 61010-1
- UL 61010-2-201
- UL 1310 Class 2 Power Units
- UL 21 ATEX 2597X
- Ex II 3 G Ex ec nC IIC T4 Gc
- IECEx ULD 21.0023X
- Ex ec nC IIC T4 Gc
- UL21UKEX2208X
- EMC Directive 2014/30/EU
- EN 61000-6-3
- EN 61000-6-4
- EN 61000-6-1
- EN 61000-6-2
- EN 61000-6-5
- IEC/EN 61850-3
- IEC 61850-3 (G,H)
- EN 55016
- EN 61000-3-2
- EN 61000-3-2 (Class A)
- EN 61000-4-3
- EN 61000-4-4
- EN 61000-4-5
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
